MOISTURE SEPARATOR

MOISTURE SEPARATOR

SKU: CEWS0XX

VORTEX WATER SEPARATOR

Centrifugal Separation to Remove up to 99% of Water Aerosol in Compressed Air.

Compressed air is normally saturated with moisture in the form of water vapor as well as aerosol, which needs to be removed to prevent downstream issues at the point of application.

Conquest’s water separator is designed using proven centrifugal separation technology to remove up to 99% of water aerosol in compressed air. It works in conjunction with other compressed air treatment products like filters, after-coolers, and dryers, enhancing their efficiency and ensuring that bulk water generated in the compressed air is properly separated and discharged.

Features & Advantages

  • Removes up to 99% bulk water.
  • Very low maintenance cost.
  • Simple and easy to install.
  • Efficient automatic drain.
  • Robust aluminum housing.

General Information

  • Pressure die-cast aluminum housing chromated for corrosion resistance, with zinc-based corrosion inhibition powder primer and epoxy polyester powder coating.
  • Injection-molded nylon bonded to the filter core using high-strength polyurethane potting resin for maximum durability.



S. No.ModelConnection BSP (F)Flow Rate Dimension (mm)Element Code
   M3/HrSCFM
1.CEWS-025½"422595X210ELWS025045X099
2.CEWS-045¾"784595X210ELWS025045X099
3.CEWS-099¾"1689995X210ELWS025045X099





The MOISTURE SEPARATOR CEWS0XX is engineered to deliver reliable and efficient moisture removal from compressed air. Leveraging centrifugal separation, it removes up to 99% of water aerosols, ensuring superior air quality. Its robust aluminum construction provides durability and corrosion resistance, while an efficient automatic drain system minimizes maintenance efforts. Ideal for industrial applications, this separator integrates seamlessly with filters, dryers, and after-coolers, making it a cost-effective solution for moisture management.
