Flow Capacity: 10 to 100 SCFM
Concept: Innovative advanced compressed air desiccant dryer with high levels of performance and reliability.
| Dryer Model | Inlet/Outlet (BSP) | Rated Flow (SCFM) |
|---|---|---|
| dd amogh-10 | ¼" | 10 |
| dd amogh-20 | ½" | 20 |
| dd amogh-30 | ½" | 30 |
| dd amogh-45 | ½" | 45 |
| dd amogh-60 | ¾" | 60 |
| dd amogh-80 | 1" | 80 |
| dd amogh-100 | 1" | 100 |
| °C | 32 | 35 | 40 | 43 | 46 | 49 |
|---|---|---|---|---|---|---|
| Factors | 1.38 | 1.20 | 1.00 | 0.72 | 0.60 | 0.50 |
Ultra-High Purity Compressed Air Desiccant Dryers offer industry-leading solutions for reliable and efficient moisture removal in compressed air systems. Designed for critical applications requiring ultra-dry air, these dryers deliver superior performance with flow capacities ranging from 10 to 100 SCFM.
Key features include compliance with ISO 8573-1986 standards, corrosion-resistant aluminum construction, and advanced filtration capabilities (pre-filter: 5 micron / 3 micron; after-filter: 0.01 micron). Engineered for low energy consumption and simplified maintenance, these dryers reduce life cycle costs while ensuring consistent and safe operation.
With a minimum operating pressure of 4 Kg./cm² and customizable configurations for MWP up to 40 Kg./cm², they are suitable for diverse industrial applications. The integrated PLC-controlled solenoid valves ensure high-efficiency moisture removal, while exhaust silencers significantly reduce noise levels.
Easy to install and ready for immediate use, the Ultra-High Purity Desiccant Dryers are an optimal choice for industries prioritizing clean, dry compressed air with reliable performance. Ideal for applications in pharmaceuticals, electronics, food processing, and other precision-driven sectors, these dryers set the standard for compressed air purity.
